JBL 2231A 15 tums bas.

Klassiker, är inlämnad för omkantning och genomgång på LN högtalarservice. I övrigt välhållna, har endast använts i hemmamiljö med ett 25 watts steg. Förväntas vara klar i slutet på Januari.

General Information

15" Low Frequency Driver
Frequency response 25Hz~2kHz ±10db
Sensitivity 93dB 1w/1m
Power capacity 100w continuous
Thiele-Small Parameters:
Fs: 16Hz
Re: 6.3Ω
Qts: 0.21
Vas: 736L
Xmax: 5.08mm
Pe Max: 100w
Dimensions WxHxD 388Øx146mm
Weight 8.6kg

The Model 2231 low frequency loudspeaker provides accurate, solid low-frequency reproductron Designed with free air resonance below the range of hearing, the 2231 has exceptional deep bass response and requires very little enclosure volume. Compared tdother loudspeakers having similar sensitivity, its frequency response is unusually linear, varying only *2 dB from 40 Hz to 800 Hz. When housed
in a properly constructed enclosure, the 2231 will exhibit exceptional. efficiency and transient response as well as the ability to handle sustained signals at high power levels without danger of mechanical damage or excessive distortion.
